Doesn't fit onto EUROSTER series, DIGO series, JAPAN, REIMS, SPORT, HISTRIX, edirb, STREAMS and ZAOU. Please choose the color: (#K04APO) Black or (#K04BPO) Red
Real leather with black alumite finish aluminum plate Auto Exe logo. Diameter: 51mm. Length: 87mm. Weight: 130g. Push type. Please choose the model from (#MND1340-03) ND roadster A/T or (#A1350-03) Universal Fit A/T Straight type (must double check the model if you own straight type model or gate type model).
Real leather with black alumite finish aluminum plate Auto Exe logo. M/T: M10x1.25, A/T: M8x1.25. Diameter: 51mm. Length: 70-88(M/T), 70-80(A/T)mm. Weight: 190g. As for M/T, it comes with shift pattarn emblem (both 6M/T and 5M/T). Please choose the model from (#A1341-03) M/T or (#A1342-03) Universal Fit A/T Gate type (must double check the model if you own straight type model or gate type model).
Spec:
Mount F/R: Stock / Stock
Rate F/R(kgf/mm): 5.0 / 3.0
Free length F/R: 180 / 190
Spring F/R: ID62 straight spring / Barrel or Taper type exclusive spring
Height adjustment range F/R: -80 to 0 / -60 to -20
*The range is when adjusting the height on the lower bracket side. *Adjustment range may change due to grade, vehicle weight... etc. *Even within the range, it may interfere with the inner fender and others. Also, please check the minimum ground clearance and set the height.
Rear damping dial Position & Shape: x
Extension dial with the product: x
Stabilizer link with the product F/R: x / x
BRAIN connection: ○ It may not fit, depends on manufacture year. Please check the chart on BLITZ HP.
For FIT, GK3, L13B engine, MY 09/2013 -
For FIT, GK5, L15B engine, MY 09/2013 -
For FIT HYBRID, GP5, LEB engine, MY 09/2013 -
Remarks: 2WD, Removing or customizing some interior parts is required for rear motor installation.
Optional parts
DSC PLUS GPS sensor kit is listed as 135-055-999
DSC PLUS remote switch is listed as 135-055-998
BLITZ DAMPER ZZ-R SpecDSC PLUS Features:
G-sensor and new motor equipped. The full-length adjustable suspension kit, which allows up to 96 levels damping force adjustment to be controlled freely from inside the vehicle.
-Equipped with "Full Auto" mode.
-Fully automatic control function that stabilizes the posture with appropriate damping force based on the number of passengers and running conditions.
-2.5-inch VA liquid crystal display.
-Damping force of four wheels can be displayed at any time.
-More intuitive operation by adopting a rotary encoder. Increased UP and DOWN button size.
-Equipped with G sensor as standard. In the map control mode, fine damping force adjustment is possible from turning G, acceleration / deceleration G, and vehicle speed.
-In addition to real-time display of G, peak display is also possible, which is convenient for setting.
-A total of 22 modes are prepared. Switchable between simple and easy STANDARD and ADVANCED with complicated and detailed control.
-The adoption of a high-performance bipolar (two-phase inversion) control motor achieves a 17% reduction in size compared to the conventional model and a 5% speedup.
-Equipped with an ambient light sensor and an auto dimmer function that automatically adjusts the brightness of the liquid crystal according to the surrounding brightness.
-With the separately sold GPS sensor kit, it is possible to control the vehicle speed linked more easily. Displays speed, time, latitude, longitude, and sea level above GPS.
Note:
This item may require an extra shipping charge depending on the destination country. If it does, we will contact you by email within 3 business days after the order is placed and tell you how much extra it costs for shipping. You can ask us to cancel the order if you would not like to pay the difference. We will proceed with the order once we receive the extra payment from you.
