All Stainless. Pipe diameter: 70-60mm. JAN CODE: 4512355190054 Remarks- Not meeting acceleration noise regulation 2010 in Japan. - JASMA proved. For EXIGA, YA5, 2.0_Turbo EJ20 engine, 4WD, Grade 2.0GT, 5AT, MY 06/2008-03/2010, Close Sound Level: 89dB(with B42332) / 86dB(with B51332), Idling Sound Level:63dB(with B44332) / 62dB(with B51332) For Legacy Touring Wagon, BR9, 2.5_Turbo EJ25 engine, 4WD, Grade 2.5GT, 5AT 6MT, MY 05/2009-03/2010, Close Sound Level: 89dB (with B21335) / 86dB(with B51335), Idling Sound Level: -

Rear pieces only. Material: All stainless Pipe diameter: φ50x2 Tail diameter: φ115(SLASH) Titan face (Blue gradation color) Position: S (Left and Right side) Consist of: 2 Weight: 9.8kg For EXIGA, YAM, 2.5_NA FB25 engine, 4WD, Grade 2.5i, CVT, MY 07/2012-03/2015, Close Sound Level: 89dB, Idling Sound Level: 58dB For EXIGA, YA5, 2.0_Turbo EJ20 engine, 4WD, Grade 2.0GT, 5AT, MY 08/2010-03/2015, Close Sound Level: 82dB, Idling Sound Level: 61dB For EXIGA CROSSOVER 7, YAM, 2.5_NA FB25 engine, 4WD, Grade 2.5i, CVT, MY 04/2015-03/2018, Close Sound Level: 89dB, Idling Sound Level: 58dB For Legacy Touring Wagon, BRG, 2.0_Turbo FA20 engine, 4WD, Grade 2.0GT DIT, CVT, MY 05/2012-10/2014, Close Sound Level: 80dB, Idling Sound Level: 57dB For Legacy Touring Wagon, BR9, 2.5_Turbo EJ25 engine, 4WD, Grade 2.5GT, 5AT 6MT, MY 04/2010-05/2013, Close Sound Level: 87dB(5AT)88dB(6MT), Idling Sound Level: - For Legacy Touring Wagon, BR9, 2.5_Turbo EJ25 engine, 4WD, Grade 2.5GT, 5AT 6MT, MY 05/2009-03/2010, Close Sound Level: 87dB(5AT)88dB(6MT), Idling Sound Level: - Remarks - Incompatible with the vehicle equipped OEM optional rear bumper skirt KAKIMOTO RACING Class KR features: - Double diffuser tail makes heavy bass sound - Special coating tail. Burnt color like titanium - Lightweight flange. Stainless steel with both durability and lightness - All stainless steel for durability - Full Tig finish. Handmade by skilled Kakimoto craftsmen. - SUS304 Hollow stay - Carved KAKIMOTO line logo on the tips

Rear piece only. Material: All stainless Pipe diameter: φ80 Silencer diameter: φ152 Tail diameter: φ115 Position: S (Left side) Consist of: 1 Weight: 7.8kg Inner silence is available as option: NIS001 For Impreza, GDA C/D/E/F/G, 2.0_Turbo EJ20 engine, 4WD, Grade WRX, 5MT/4AT, MY 11/2002-06/2007, Close Sound Level: 91dB, Idling Sound Level: 66dB, JASMA approved For Impreza, GGA C/D/E/F/G, 2.0_Turbo EJ20 engine, 4WD, Grade WRX, 5MT/4AT, MY 11/2002-06/2007, Close Sound Level: 92B, Idling Sound Level: 66dB, JASMA approved KAKIMOTO RACING HYPER FULLMEGA N1 + Rev. features: -Redesigned the racing muffler into a street model that meets JASMA standards. The design was made with the aim of achieving the best specifications that can fully demonstrate the street spec engine performance. Improving power response at high speeds and securing torque at medium and low speeds so as ease of handling on the street use. A high-spec model was born that was more aggressive and aggressive on the street. -The racy sound is on the edge of JASMA standards. -A simple shell type reminiscent of a racing muffler. High quality with all stainless steel.

Rear piece only. Material: All stainless Pipe diameter: φ80 Tail diameter: φ115 Position: S (Left side) Consist of: 1 Weight: 7.5kg For Impreza, GDA C/D/E/F/G, 2.0_Turbo EJ20 engine, 4WD, Grade WRX, 5MT/4AT, MY 11/2002-06/2007, Close Sound Level: 92dB, Idling Sound Level: 71dB, JASMA approved For Impreza, GGA C/D/E/F/G, 2.0_Turbo EJ20 engine, 4WD, Grade WRX, 5MT/4AT, MY 11/2002-06/2007, Close Sound Level: 92B, Idling Sound Level: -dB, JASMA approved Kakimoto.R Features: - High quality sound with deep bass. - High torque and high power that does not disappoint. - An all-round muffler that balances sound and performance. - JASMA approved

Material: All stainless Pipe diameter: φ80 Silencer diameter: φ150 Tail diameter: φ100 Titan face (Blue gradation color) Position: S (Left side) Consist of: 2 Weight: 11.9kg Inner silencer is available as option: RIS001 For Impreza, GDB A/B/C/D, 2.0_Turbo EJ20 engine, 4WD, Grade WRX STI, 6MT, MY 10/2000-06/2004, Close Sound Level: 93dB, Idling Sound Level: 69dB, JASMA approved For Impreza, GDA A/B, 2.0_Turbo EJ20 engine, 4WD, Grade WRX NB, 5MT/4AT, MY 08/2000-11/2002, Close Sound Level: -dB, Idling Sound Level: -dB, JASMA preparing for application For Impreza, GGB A/B, 2.0_Turbo EJ20 engine, 4WD, Grade STI, 6MT, MY 10/2000-11/2002, Close Sound Level: -dB, Idling Sound Level: -dB, JASMA preparing for application For Impreza, GGA A/B, 2.0_Turbo EJ20 engine, 4WD, Grade 20K, 5MT/4AT, MY 08/2000-11/2002, Close Sound Level: 93B, Idling Sound Level: 69dB, JASMA approved KAKIMOTO RACING Regu.06 & R features: - While meeting JASMA standards, it does not sacrifice performance. A tuning muffler that follows the racing spirit of Kakimoto Kai. - Focuses street use, it maximizes performance, such as Medium / low speed torque, power-up in all range, quick response. - Comfortable sound for enjoying exhaust tune, 92dB (without inner silencer) as standard. Inner silencer is available as option. - Titanium burnt special coating tail (patented), full Tig welding, high quality with full stainless steel.

Price is per a piece. Optional part for Regu.06 & R Regu.06 & R is manufactured to meet Japanese safety standards without an inner silencer. If you need it, it is available as an option part.

Spec: For competition, circuit only. Street use prohibited in Japan. Rear piece only. Material: All stainless Pipe diameter: φ60 Silencer diameter: φ115 Tail diameter: φ80 Position: S (Right side) Consist of: 1 Weight: 2.4kg For Roadster ND5RC 1.5_NA Grade:S RS NR-A, 6MT, MY05/2015-, Close Sound Level: 111dB, Idling Sound Level: 73dB For Roadster ND5RC 1.5_NA Grade:S, 6AT, MY05/2015-07/2018, After 07/2018 unconfirmed, Close Sound Level: 111dB, Idling Sound Level: 73dB For RoadsterRF NDERC 2.0_NA Grade:S VS RS, 6MT, MY07/2018-, Close Sound Level: 111dB, Idling Sound Level: 70dB For RoadsterRF NDERC 2.0_NA Grade:S VS RS, 6MT, MY12/2016-07/2018, After 07/2018 unconfirmed, Close Sound Level: 108dB, Idling Sound Level: 77dB For RoadsterRF NDERC 2.0_NA Grade:S VS, 6AT, MY12/2016-07/2018, After 07/2018 unconfirmed, Close Sound Level: 107dB, Idling Sound Level: 76dB KAKIMOTO RACINGGT1.0Z Racing Features: GT1.0ZRacing is the world´s strongest ultra-lightweight and ultra-high performance racing muffler developed based on the concept of "Faster in 0.1 seconds!" The exhaust efficiency that maximizes the performance of a full-tuned engine with a focus on high rev and circuit driving. Full straight structure completely without sub silencer for the turbo car. (For NA, a sub-silencer with a slight throttle is added to secure torque) Because of exhaust efficiency, the sound is little loud, but the clear sound quality that makes you feel like this is the "Kakimoto Sound" that makes the racing spirit heat up. For weight reduction, main pipe of 1.0mm thickness, lightweight flange, hollow stay, etc are used in.

For Legacy B4, 2.5i eyesight, L package, S package, S-style. All stainless. Pipe diameter: 50mm Tail diameter: 115 slash (blue gradation color) Including Gasket x1, Bolt x2, Nut x2. Rear peace only.

Spec: Rear piece only. Material: All stainless Pipe diameter: φ60 Tail diameter: φ70 (SLASH) Blue gradation color Position: W (Right side) Consist of: 1 Weight: 6.6kg For Roadster ND5RC 1.5_NA Grade:S, 6MT, MY05/2015-, Close Sound Level: 94dB, Idling Sound Level: 64dB For Roadster ND5RC 1.5_NA Grade:S, 6AT, MY05/2015-07/2018, After 07/2018 unconfirmed, Close Sound Level: 94dB, Idling Sound Level: 63dB For RoadsterRF NDERC 2.0_NA Grade:S VS RS, 6MT, MY07/2018-, Close Sound Level: 93dB, Idling Sound Level: 62dB For RoadsterRF NDERC 2.0_NA Grade:S VS RS, 6MT, MY12/2016-07/2018, Close Sound Level: 92dB, Idling Sound Level: 62dB For RoadsterRF NDERC 2.0_NA Grade:S VS, 6AT, MY12/2016-07/2018, After 07/2018 unconfirmed, Close Sound Level: 88dB, Idling Sound Level: 64dB KAKIMOTO RACING Class KR features: - Double diffuser tail makes heavy bass sound - Special coating tail. Burnt color like titanium - Lightweight flange. Stainless steel with both durability and lightness - All stainless steel for durability - Full Tig finish. Handmade by skilled Kakimoto craftsmen. - SUS304 Hollow stay - Carved KAKIMOTO line logo on the tips

For FB25 4WD CVT. MY 10/2014-10/2017, Rear pieces only. Material: All stainless Pipe diameter: φ50 Tail diameter: φ115(SLASH) Titan face (Blue gradation color) Position: S (Left side) Consist of: 1 Weight: 5.2kg Close Sound Level: 92dB, Idling Sound Level: 59dB KAKIMOTO RACING Class KR features: - Double diffuser tail makes heavy bass sound - Special coating tail. Burnt color like titanium - Lightweight flange. Stainless steel with both durability and lightness - All stainless steel for durability - Full Tig finish. Handmade by skilled Kakimoto craftsmen. - SUS304 Hollow stay - Carved KAKIMOTO line logo on the tips
