For Subaru BRZ ZC6 MY:03/2012 - Engine：FA20 / Transmission：MT AT / Attachment position：R Standard diff type：Open type differential / Torque sensing differential 3 type available and the initial setting. - 1&2WAY initial setting 1WAY (LSD 986 E) or 2WAY(LSD 986 E2) - 1.5&2WAY initial setting 1.5WAY (LSD 986 K15) or 2WAY (LSD 986 K2) - 1.5WAY initial setting 1.5WAY (LSD 986 M15) Remarks - Circuit spec LSD Link: CUSCO LSD type-MZ features (html), CUSCO LSD GUIDE (pdf)

For Subaru BRZ ZC6 MY:03/2012 - Engine：FA20 / Transmission：MT AT / Attachment position：R Standard diff type：Open type differential / Torque sensing differential 3 type available and the initial setting. - 1&2WAY initial setting 1WAY (LSD 987 E) or 2WAY(LSD 987 E2) - 1.5&2WAY initial setting 1.5WAY (LSD 987 K15) or 2WAY (LSD 987 K2) - 1.5WAY initial setting 1.5WAY (LSD 987 M15) Remarks - Circuit spec LSD This cannot be used with normal final gear. This is for the OEM Toyota 4.875 final gear (Part number 41201-69615) and 5.125 final gear (Part number 41201-29736). Following TOYOTA OEM parts are required for installation. - Rear Drive Pinion Companion Flange (Toyota P/N 41204-35082)(Japanparts P/N 376-190-006) - Rear Differential Drive Pinion Oil Spring (41214-26011)(Japanparts P/N 376-190-007) - Rear Differential Drive Pinion Bearing Spacer (41231-24010)(Japanparts P/N 376-190-008) - Rear Differential Carrier Oil Seal (90311-41009)(Japanparts P/N 376-190-009) Link: CUSCO LSD type-MZ features (html), CUSCO LSD GUIDE (pdf)

For Subaru BRZ ZC6 MY:03/2012 - Engine：FA20 / Transmission：MT AT / Attachment position：R Standard diff type：Open type differential / Torque sensing differential 3 type available and the initial setting. - 1&2WAY initial setting 1WAY (LSD 987 F) or 2WAY(LSD 987 F2) - 1.5&2WAY initial setting 1.5WAY (LSD 987 L15) or 2WAY (LSD 987 L2) - 1.5WAY initial setting 1.5WAY (LSD 987 V15) Remarks - Circuit spec LSD This cannot be used with normal final gear. This is for the OEM Toyota 4.875 final gear (Part number 41201-69615) and 5.125 final gear (Part number 41201-29736). Following TOYOTA OEM parts are required for installation. - Rear Drive Pinion Companion Flange (Toyota P/N 41204-35082)(Japanparts P/N 376-190-006) - Rear Differential Drive Pinion Oil Spring (41214-26011)(Japanparts P/N 376-190-007) - Rear Differential Drive Pinion Bearing Spacer (41231-24010)(Japanparts P/N 376-190-008) - Rear Differential Carrier Oil Seal (90311-41009)(Japanparts P/N 376-190-009) The shift indicator will not be displayed correctly when the final is changed. Link: CUSCO LSD type-RS features (html), CUSCO LSD GUIDE (pdf)

For MT MY08/2016-(Kouki) 2mm bigger in diameter than stock part. You can feel more power, torque and accelerator response by efficient intake air. Just replace stock throttle with this part. You don't need to reset of ECU.

http://www.cuscousainc.com/downloads/dl/file/id/177/965_012_an_engine_oil_parts_air_water_oil_cooler_kit_toyota_86_scion_fr_s_subaru_brz_zn6_zc6.pdf

For MT/ AT MY04/2012 - 07/2016(Zenki) and AT MY08/2016-(Kouki) 2mm bigger in diameter than stock part. You can feel more power, torque and accelerator response by efficient intake air. Just replace stock throttle with this part. You don't need to reset of ECU.

Rear side. Required 1sets. Price is for per set. Includes rubber boots.

Required 1sets. Price is for per set. Rear side. Includes rubber boots.

55 degree with 1 way. For SE3P 13B-MSP MT after 2003/06. Attachment position is rear. Standard Diff Type has to be Torsen.

55 degree with 1 way. For FD3S 13BRE-W MT after 1991/11. Attachment position is rear. Standard Diff Type has to be Torsen.
