  • TEIN
  • STREET ADVANCE Z (GSM98-91AS3)
  • (Japanparts No :

    233-100-623

    )

 Click on the image above to enlarge

  • 117,700 JPY  (
    Convert

    Home Currency Selection

    Select your home currency from the list below.
    Then click on "Set Home Currency" button to set your home currency.

    )
  • You save 24,717JPY
  • 92,983 JPY  (
    Convert

    Home Currency Selection

    Select your home currency from the list below.
    Then click on "Set Home Currency" button to set your home currency.

    )
  • Quantity :

add to Wish List

item is added to Wish List

already added to Wish List

Member page Login

Please input your Email address and password.

Email address
Password
Estimated delivery time by EMS/Courier
10-15 days
  • Car category
  • Mazda

    • Axela <Mazda 3> BL

  • Compatible with:
  • BL3FW, Grade- MAZDASPEED, 2300cc, FF, MY 06/2009 - 11/2013
  • Product
    Details
  • Ask about
    Product
  • Ratings and
    Review

Suspension & Steering

 >

Coilovers

Product Information

SPRINGS: included
EDFC compatibility: available. If you would like to buy EDFC, leave the message in the comment field in the process of ordering. Pay us later by PayPal.
Damping force adjustment: Front- available / Rear- available
Full-length ride-height adjustable: Front- N/A / Rear- N/A
Upper mount: Front- UPPER MOUNTS not included.(Please use OE.) / Rear- UPPER MOUNTS not included.(Please use OE.)
Base ride height drop(mm): Front: -35 / Rear: -25
Ride height adjustable range(mm): Front: MAX LOW - HI: -64 to -15, RECOMMENDED LOW - HI: -45 to -25 / Rear: MAX LOW - HI: -51 to -15, RECOMMENDED LOW - HI: -35 to -15
Spring: Front: RATE(N/mm / Kgf/mm): 49.0/5.0, FREE LENGTH(mm)/I.D.(mm): 225/ / Rear: RATE(N/mm / Kgf/mm): 39.2/4.0, FREE LENGTH(mm)/I.D.(mm): 194/
[ NOTE ] IF LOWERING BELOW RECOMMENDED RIDE HEIGHT RANGE USING OE TIRE/WHEEL SIZE, SPRING SEAT MAY INTERFERE WITH TIRE. MAKE SURE TO CHECK THERE IS NO INTERFERENCE, BEFORE ADJUSTING RIDE HEIGHT. RECOMMENDED TIRE: 225/40-18, WHEEL: 18X7.5J INSET LESS THAN 48.
Check TEIN page for details

For MAZDASPEED AXELA, BL3FW, Grade- MAZDASPEED, Engine- 2300cc, Drive train- FF, MY 06/2009 - 11/2013

Features:
Incredibly low price - Shock absorber for street use with an astonishing price tag.
Sealed Structure
Thread-Type ride height adjustment
Twin-tube system
Uses OE mounts
High durable & reliability- TEIN-Green Powder Coating, Special Surface Treatment "ZT Coating"
Damping force adjustable

Note:
This item may require an extra shipping charge depending on the destination country. If it does, we will contact you by email within 3 business days after the order is placed and tell you how much extra it costs for shipping. You can ask us to cancel the order if you would not like to pay the difference. We will proceed with the order once we receive the extra payment from you.
